GEPRC GEP-CL-20 Cinelog 20 CL20 2″ Frame Kit

📝 Description:

The GEPRC GEP-CL20 Cinelog 20 is a purpose-built 2-inch cinewhoop frame kit, ideal for indoor flying and narrow environments. Designed with a vibration-damping camera gimbal and lightweight structure, the CL20 delivers smooth, jello-free footage while maintaining agility and control.

It supports various HD camera setups including DJI O3, Naked GoPro (GP8/9/10/11), Insta360 Go2, and DJI Action2, and is compatible with 25.5×25.5mm and 20x20mm VTX/F4 FC stacks. The 9x9mm motor mounts are suitable for high-performance 1303.5 motors, giving you powerful yet stable flight.

Whether you’re a cinematic pilot, indoor flyer, or freestyle enthusiast, the CL20 frame is an excellent platform to build your next micro cinewhoop.

⭐ Key Features:

• 🛠️ Precision-engineered 2” Frame – Built with durable carbon fiber plates (2.5mm main plate) for strength and lightweight agility.

• 📹 Camera Vibration Isolation Gimbal – Includes soft-mounted gimbal system to reduce FPV jello and improve HD footage quality.

• 🪶 Lightweight Compact Build – Ideal for flying in tight indoor or urban environments.

• 🎥 Camera Compatibility – Mounts Naked GoPro 8/9/10/11, Insta360 GO2, DJI Action2, and DJI O3 VTX.

• 💨 Pusher Prop Design – Inverted propeller orientation increases stability and cinematic smoothness.

• 🔧 Flexible Mounting Options – Compatible with 25.5×25.5mm & 20x20mm mounting for FC and VTX.

• 🧩 Complete Hardware Kit – Includes CNC columns, screws, soft dampers, and 3D-printed parts for accessories.

📊 Specifications:

📦 Package Includes:

🔹 Carbon Fiber Plates:

• 1 × Main Plate (2.5mm)

• 1 × Bottom Plate (1.5mm)

• 1 × Camera Gimbal Plate (2.0mm)

• 1 × Motor Plate Gasket (2.0mm)

🔹 Hardware & Screws:

• Full set of M2 screws (4mm to 16mm), self-clinching nuts, nylon nuts & spacers

• CNC aluminum standoffs and shock-absorbing grommets

• EVA damping rings

• Silicone gaskets

• Camera gimbal dampening rubbers

🔹 3D Printed Mounts:

• VTX Antenna Mounts (Large & Small Hole)

• TBS Antenna Mount

• Receiver Mounts (2 types)

• Camera Mounts (1 Hole & 2 Holes)

🔹 Injection Molded Parts:

• 4 × Prop Guards

🔹 Other Accessories:

• 1 × Naked GoPro 8 Base

• 1 × 4S Naked GP Power Cable

• 2 × Battery Anti-slip Pads

• 2 × Damping Pads

• 2 × Receiver Antenna Tubes (100mm)

• 2 × Battery Straps (15x150mm)

• 1 × L-shaped Screwdriver (1.5mm)

• 2 × 3M Double-sided Tapes

• 1 × Keychain
